Goal Zero · Folding briefcase (aluminum + polymer shield)
Goal Zero Ranger 300 Briefcase
Solar savings: 2 panels — 10%; 3 panels — 13%; 4 panels — 15%; 5 panels — 18%. Maximum 5 panels per purchase; mix models. Panels inside kits do not count. Offers do not stack.
Based on 1 separately purchased panel after adding this selection. Final total is confirmed in your bag.
Overview & Key Strengths
Why this solar panel
The Goal Zero Ranger 300 Briefcase (32410) packs 300W of monocrystalline solar capacity into a 4-panel hinged ETFE-and-aluminum briefcase that weighs only 39.0 lb (17.7 kg) — Lighter than the 200W glass Boulder 200 Briefcase while producing 50% more power.
Patent-pending auto-deploying kickstands fold out automatically as you open the panels, and the integrated 6 ft High Power Port (HPP) lead connects straight to Goal Zero Yeti 500, 700, X-series, and Yeti PRO 4000 stations.
- A Nomad/Boulder compromise: 300W from 4 linked 75W panels.
- Aluminum frame, polymer shield instead of glass.
- Kickstand, bag.
- Lighter than 3× Boulder 100.
- For high solar load.
Spec sheet
Full specs
- Brand
- Goal Zero
- Model / MPN
- 32450
- UPC / GTIN
- 847974007990
- Type
- Folding briefcase (aluminum + polymer shield)
- Rated Power
- 300 W
- Connector
- HPP
- Weight
- 39 lb / 17.7 kg
- Folded / Panel Size
- 26.5 × 24.5 × 2.9 in / 67.3 × 62.2 × 7.4 cm (closed)
- Cell Chemistry
- Monocrystalline Silicon (ETFE + Aluminum Frame)
- Peak Power
- 300 W (4 × 75W Hinged Sections)
- Open Circuit Voltage (Voc)
- 23.0 V
- Max Operating Voltage (Vmp)
- 19.3 V
- Short Circuit Current (Isc)
- 16.0 A
- Max Operating Current (Imp)
- 15.5 A
- Unfolded Dimensions
- 30.6 × 106.0 × 0.9 in (77.7 × 269.0 × 2.3 cm)
- Output Connector
- Goal Zero High Power Port (HPP)
- Compatible Stations
- Goal Zero Yeti 500, 700, 1000X, 1500X, 3000X, 6000X, Yeti PRO 4000
Estimated full-sun charge time
- Small station (300 Wh)
- ~1.5 h
- Mid station (1,000 Wh)
- ~5.5 h
- Large station (2,000 Wh)
- ~11 h
0–100% estimate for one panel in strong, direct sun with good angle. Clouds, haze, shade, and the station's own solar-input limit will slow this down in practice.
In action
Reference setups & field deployment
Goal Zero Ranger 300 Briefcase deployed at an off-grid cabin deck
Four-panel 300W array with thin aluminum framing and auto-deploying leg stands.
Four-section hinged frame with signature orange corner hinges
Combines rigid aluminum perimeter stability with lightweight ETFE polymer encapsulation.
Auto-deploying rear kickstands & padded carry bag
Kickstands pop out automatically as you unfold the four-section briefcase.
Highlights
Why it's worth it
- 300W output in a lightweight aluminum-framed ETFE 4-panel briefcase (39.0 lb / 17.7 kg)
- Auto-deploying rear leg stands pop into position automatically as you unfold the briefcase
- Native High Power Port (HPP) output with 23.0V Voc / 19.3V Vmp electrical curve
- Magnetic corners and integrated handles make folding and packing fast for one person
In the box
What's included
- Goal Zero Ranger 300 Briefcase Solar Panel (with 6 ft HPP Cable)
- Padded Canvas Protective Carry Bag
- User Guide
