BLUETTI · Folding fabric
BLUETTI 200W Portable Solar Panel (PV200 / SP200L)
Solar savings: 2 panels — 10%; 3 panels — 13%; 4 panels — 15%; 5 panels — 18%. Maximum 5 panels per purchase; mix models. Panels inside kits do not count. Offers do not stack.
Based on 1 separately purchased panel after adding this selection. Final total is confirmed in your bag.
Overview & Key Strengths
Why this solar panel
The BLUETTI PV200D (200W) Portable Solar Panel is the workhorse 4-fold solar panel for BLUETTI AC70, AC180, Elite 100 V2, Elite 200 V2, and AC200L portable power stations.
Built with 23.4% monocrystalline cells laminated in tough ETFE film and rated IP67 against water and dust, its 20.4V Vmp / 24.6V Voc profile allows up to two panels in series on the AC180 (500W max) or up to five in series on the AC200L.
- Most versatile BLUETTI 200W.
- 23.4% efficiency.
- IP65.
- Voc 26.1V / Vmp 20.5V.
- 4 folds, kickstands.
- ETFE.
- 7.3kg.
- For AC70 / AC180 / Elite 200 V2.
- 12 AWG cable.
Spec sheet
Full specs
- Brand
- BLUETTI
- UPC / GTIN
- 193022000131
- Type
- Folding fabric
- Rated Power
- 200 W
- Connector
- MC4 + XT60–MC4 cable
- Weight
- 16.1 lb / 7.3 kg
- Folded / Panel Size
- 24.6 × 21.9 × 1.7 in / 62.5 × 55.6 × 4.3 cm (folded)
- Cell Chemistry
- Monocrystalline Silicon (ETFE)
- Cell Efficiency
- Up to 23.4%
- Open Circuit Voltage (Voc)
- 24.6 V
- Max Operating Voltage (Vmp)
- 20.4 V
- Short Circuit Current (Isc)
- 10.8 A
- Max Operating Current (Imp)
- 9.7 A
- Unfolded Dimensions
- 82.8 × 23.9 × 1.2 in (210.5 × 60.8 × 3.0 cm)
- Weather Resistance
- IP67 Water & Dust Resistant
- Compatible Stations
- BLUETTI AC70, AC180, Elite 100 V2, Elite 200 V2, AC200L, Apex 300
Estimated full-sun charge time
- Small station (300 Wh)
- ~2.5 h
- Mid station (1,000 Wh)
- ~8.5 h
- Large station (2,000 Wh)
- ~17 h
0–100% estimate for one panel in strong, direct sun with good angle. Clouds, haze, shade, and the station's own solar-input limit will slow this down in practice.
In action
Reference setups & field deployment
BLUETTI PV200 200W Solar Panel charging an AC180 / Elite 200 V2 in camp
Propped on its rear kickstands in a sunny clearing with MC4-to-XT60 solar connection.
Multi-angle rear kickstands and MC4 junction box
Adjusts between 35°, 45°, and 55° to maximize midday and afternoon sun harvest.
Folded briefcase carry handle & snap latches
Spans 82.8 × 23.9 in when deployed and folds into a compact 24.6 × 21.9 in briefcase.
Highlights
Why it's worth it
- 200W rated output with up to 23.4% monocrystalline silicon conversion efficiency
- IP67 waterproof and dustproof ETFE lamination for long-term outdoor durability
- 3-angle adjustable rear kickstands (35° / 45° / 55°) for fast field alignment
- 24.6V Voc / 20.4V Vmp electrical curve makes series chaining simple and safe
In the box
What's included
- BLUETTI 200W Portable Solar Panel (PV200D)
- Pre-Attached 3 m MC4 Solar Charging Cable
- User Manual & Warranty Card
